Shandong Yaohua Glass Bent Curved tempered toughened glass CE AS/NZS 10mm 12mm 15mm 19mm

  • 100 - 999 Boxes
    $25.00
  • >=1000 Boxes
    $16.00
Color:
Brown Blue Light Grey Clear Light Green
Lead Time:
Quantity(Boxes) 1 - 2000 >2000
Est. Time(days) 15 Negotiable
Customization:
Customized logo (Min. Order: 1 Boxes)
Graphic customization (Min. Order: 1 Boxes)

More

Customized packaging (Min. Order: 1 Boxes) Less
Report Suspicious Activity
Overview
Quick Details
Warranty:
More than 5 Years
After-sale Service:
Online Technical Support, NONE
Project Solution Capability:
graphic design, Others
Place of Origin:
Shandong, China
Brand Name:
Shandong Yaohua
Model Number:
tempered glass
Function:
Acid Etched Glass, Low-E Glass
Shape:
Curve, Flat
Structure:
Solid
Technique:
Clear Glass, Coated Glass, Frosted Glass, Tempered Glass, Tinted Glass
Type:
Float Glass
Product name:
curved tempered
Max size:
3300*13000mm
Radius:
R=1300mm
Application:
Shower, door, balustrade, glas wall, padel etc
Edges Treatment:
Polished Grind
Packing:
Plywood Crates
Certificate:
CCC/ISO9001/CE/SGCC/Australian Certificate
Glass thickness:
3mm -19mm
Material:
Auto Grade Float Glass
Delivery time:
7-15 Days
Supply Ability
Supply Ability:
2000 Square Meter/Square Meters per Day
Packaging & Delivery
Packaging Details
Plywood crates, corks or paper between glass
Port
QINGDAO
Picture Example:
package-img
Lead Time :
Quantity(Boxes) 1 - 2000 >2000
Est. Time(days) 15 To be negotiated

Shandong Yaohua Glass Bent Curved tempered toughened glass CE AS/NZS 10mm 12mm 15mm 19mm



Glaston CCS900 tempering furnace #1:



Tempered or toughened glass is a type of safety glass processed by controlled thermal or chemical treatments to increase its strength compared with normal glass.

Tempered glass is made by heating and cooling a piece of standard glass in a tempering furnace. The glass, which must be pre-cut and edged before being put into the tempering furnace, is heated to approximately 1200°F and then cooled rapidly.

This process is also known as quenching. The quenching process leaves the glass hardened so that it is now approximately 4 to 5 times stronger, and therefore more resistant to breakage, then it was before the tempering process. If it does break, tempered glass shatters in small pieces that are less likely to cause injury or damage than non-tempered glass.



Tempering furnace #2 (Gaston FC500) and #3 (TCMC)



INTERMAC CNC:





Product Description

 Tempered glass specification

Thickness

3mm-19mm

Max Size

13000mm*3300mm

Mini Size

200mm*300mm

Color

Clear, low iron (ultra clear), bronze, grey, blue, green, low-E, reflective

Standardization

GB15763, AS/NZS2208:1996 , EN 12150-1, CAN/CGSB 12.1-2017,  ANSI Z97.1-2015

Package

Protective paper interlayer, plywood crate



Curved tempered glass specification

Thickness

5mm-19mm

Max Size

5000mm*2500mm

Mini curved radius

1500mm

Color

Clear, low iron (ultra clear), bronze, grey, blue, green, low-E, reflective

Standardization

GB15763, AS/NZS2208:1996, EN 12150-1

Package

Protective paper interlayer, plywood crate







Strict inspection for good quality tempered glass stress, holes, size, surface etc.
(Our QC team will inspect each thickness and every two hours.)



Drilling holes:

Company Information



Shandong Yaohua GlassCo., Ltd,with over 30 years continual development and grandness, has become amodern glass deep processing enterprise which has two large workshops withmodern standard, has several production and sales shop. And our fixed assetshas reached 80 million RMB, and we have the manufacturingsites about 40 thousand square meter, and more than 300staff. Yaohua become one of the best factories in China .

  Our company has Quality Management SystemCertificate ,CCC Certificate, CE Certificate for Euro, AS/NZS Certificate forAustralia and SGS Certificate for USA. Production depends on LOW-E glass,tempered glass, insulating glass, laminated glass, silk screen glass, hot bentglass, bullet-proof glass, 15mm, 19mm jumbo size glass and other kinds of deepprocessing glass. Our advanced production facility and abundant technologystrength ascertained the best quality of products. Our products have reached onthe leading level in China at present and have exported to different part ofthe world. Many famous constructions in Jinan, Shandong even through China haveused the glass in brand of Shandong Yaohua.



Our Office:



PACKING & LOADING:

Our Services



Why choose us?

1.35 years experience on glass, 15years exporting, 1200 containers exported one year.

2.Comply with AS/NZS2208:1996 , EN 12150-1, CAN/CGSB 12.1-2017,  ANSI Z97.1-2015

If need any certificate, please contact us.

3.Imported world advanced equipment.

Lisec Cutting, Glaston Grinding, Glaston Tempering Furnace, Lisec and Bystronic IGU line etc

4.Various glass & fast delivery time.

Normally need 10-14 days.

5.Strict quality control management.

Do our best to meet your demand.

6.Professional packing team for years.

7.Competitive price and quality.

8.Granted both Shandong Province Famous Trademark and Shandong Province Famous Band Products.

9.Using Auto Grade float glass (Grade A) in domestic

10.fast and effective logistics service for our customers;





Welcome to contact us once you have any questions, 7X24:
